4 / 12 P/N PAK200929-ML • REV B • ISS 07OCT22
Note: It is important to install the rubber band in addition to the
plastic cover of the battery. See Figure 5.
Commissioning
1. Fit option Links:
a. Sounder cut-off timer: T1 and T2
b. Select SAD mode on/off as required
c. Set the strobe trigger / FLi link as required.
d. Set the ring trigger / BLi link as required.
See “Options selection” on page 2 for details.
2. Connect AP(S)/AP(R) as required depending on single or
multiple Sounder installation, see Figures 3 and 4.
3. Connect FAUTE, BL+.
4. Connect TEST if the remote test facility is required.
5. Connect ING to ALIM+/H+ or a switched output of control
panel set high (optional to disable sounder)
6. Connect ALIM+/H+ and ALIM−/H−.
7. Apply power to the sounder via ALIM+/H+ and ALIM−/H−
from control panel.
8. Connect the red and black battery leads to correct(!)
terminals of battery.
9. If the ING input has been connected as step 5, then once
the cover is fitted and screw tightened, the AS700G3 will
perform a self-test. This takes approximately 10 seconds.
If the battery is faulty the unit will indicate this with a series
of continuous fast clicks.
10. If ING input has been connected as step 5, then remove
this link.
Note: Sounder will activate if SAD Mode is selected, and
cover is removed.
11. Fully test Sounder functionality
12. Commissioning complete.
Note: If commissioning sequence is omitted (sounder is
connected to ALIM+/H+ / ALIM−/H− and battery supplies
with ING input at 0 V), then immediately after ALIM+/H+
and ALIM−/H− connected, active Auto-protection
conditions will not be processed until:
a. 6 seconds after ALIM+/H+ and ALIM−/H− applied
— and —
b. The Auto-protection condition is first cleared and then a
new Auto-protection event is generated
Maintenance
The AS700G3 sounder should be tested for correct operation
on a periodic basis. A minimum of one check every 12 months
is recommended. The following features should be verified on
each maintenance visit:
1. Correct operation of sounder from control panel signals
2. Correct operation of cover and rear Tampers.
3. Remove the ALIM+/H+ supply from the control panel and
check that the internal battery voltage as measured
between BAT+ and BAT− is greater than 12.0 VDC. If the
battery voltage is less than this value, replace the battery
and reconnect observing CORRECT polarity.
4. Check for signs of significant water or insect ingress.
Clean as necessary.
Battery removal
The battery may be removed for disposal at end of product life
or if it is detected faulty by the sounder self-test. To remove,
disconnect red and black leads from the battery terminals,
unclip rubber retaining band, and withdraw the battery from its
holder. To fit a new battery, insert into holder, and reconnect
positive (RED) and negative (BLACK) leads to CORRECT
positive and negative battery terminals. Refit rubber retaining
band.
IMPORTANT: Ensure correct polarity of connections. If either
battery lead has become detached from the terminal block,
ensure that exposed battery leads DO NOT accidentally cause
a short circuit, then secure positive (RED) lead to BAT+ and
negative (BLACK) lead to BAT−.
Dispose of used batteries in accordance with all national and
local regulations.
Diagnostics
Table 3 : Diagnostic tones
