6
Installing the Pump The pump should be installed as follows:
1. Position the pump, feet down, on any convenient horizontal
surface or alternatively suspend from the bed foot rail by
means of the integral hanging brackets.
2. Ensure that the mattress tube-set is not "kinked" or twisted
and connect it to the pump until it clicks into place. Ensure
that the tube-set is securely connected to the pump.
3. Insert the mains power plug into a suitable mains power
socket.
4. Put the mains cable under the mattress using the three
mattress cable ties. The magic cable tie can be used to
manage the surplus cable by the bed foot rail.
System Operation The system is now ready for use. Refer to Page 9 “Mattress -
Pump Operation” for day-to-day operating instructions.
WARNING
Make sure that the mains power cable is positioned to avoid causing a hazard
and is clear of moving bed mechanisms or other possible entrapment areas.
