Electromagnetic Compatibility
001.08075.EN rev. 22
Electromagnetic Immunity
Guidance and Manufacturer’s Declaration -
Electromagnetic Immunity - For all Equipment and Systems
The VoyagerLVLQWHQGHGIRUXVHLQHOHFWURPDJQHWLFHQYLURQPHQWVSHFL¿HGEHORZ7KHFXVWRPHURUWKH
user of the Voyager should assure that it is used in such an environment.
Immunity test IEC 60601 test level Compliance level
Electromagnetic
environment - Guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±8 kV contact
±15 kV air
±8 kV contact
±15 kV air
Floors should be wood,
concrete or ceramic tile.
,IÀRRUVDUHFRYHUHGZLWK
synthetic material, the relative
humidity should be at least
30%.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV, AC Mains
±1 kV, I/O Ports 100 kHz
repetition frequency
±2 kV, AC Mains
±1 kV, I/O Ports
100 kHz repetition
frequency
Mains power quality should be
that of a typical commercial or
hospital environment.
Surge
IEC 61000-4-5
±2 kV, AC Mains, Line to
Ground
±1 kV, AC Mains, Line to
Line
±2 kV, AC Mains, Line
to Ground
±1 kV, AC Mains, Line
to Line
Mains power quality should be
that of a typical commercial or
hospital environment.
Voltage dips,
short
interruptions and
voltage variations
on power supply
input lines
IEC 61000-4-11
87F\FOH
At 0°, 45°, 90°, 135°,
180°, 225°, 270° and
315°
87F\FOH
and
87F\FOHV
Single phase: at 0°
87F\FOH
87F\FOH
At 0°, 45°, 90°, 135°,
180°, 225°, 270° and
315°
87F\FOH
and
87
cycles
Single phase: at 0°
87
cycle
Mains power quality should be
that of a typical commercial or
hospital environment.
Power frequency
(50/60 Hz)
PDJQHWLF¿HOG
IEC 61000-4-8
30 A/m
50/60 Hz
30 A/m
50/60 Hz
Power frequency magnetic
¿HOGVVKRXOGEHDWOHYHOV
characteristic of a typical
location in a typical
commercials or hospital
environment.
NOTE: U
T
is the AC mains voltage prior to application of the test level.
