Removing the Tank
1. Operate menu to “MANUAL DRAIN” and allow unit to complete a deep drain.
(Caution:Tankwillstillbequitewarm).
2. Turn off circuit breaker.
3. Unlock and open front and side doors. Remove left side panel and top panel.
4.Disconnect3hosesfromfrontoftank;rubberhosecuffatsteamoutlet;heatingelementleadsat 
 contactor,fuses,orpowermodule;andthermocoupleandaquastatwires.
5. Loosen and remove 4 mounting bolts at the bottom of tank. Slide tank out left side of cabinet
 (besuretankhadtimetocoolafteroperation).
Troubleshooting
Notice: This troubleshooting guide is offered to aid in servicing the HC-6000 humidifiers. It is intended
for use by electricians and technical service personnel familiar with electrical and electronic equip-
ment. Many steps in the troubleshooting procedures require measurements of high voltages and
involve working near exposed live parts. KNOW WHERE THE HIGH VOLTAGE PARTS ARE, AND
KEEP HANDS AND METAL TOOLS AWAY FROM THEM. All resistance checks should be made
with main power OFF and the component disconnected from wiring. All continuity checks should be
made with main power OFF. If unsure concerning any of the following procedures, PLEASE consult
theArmstrongHumidificationGroupat(269)273-1415.
Humidifier will not fill with water when power is applied.
1. Make sure the status in Operation Setup menu in is “Steam Gen.”.
2. If “STATE” LED is red, refer to MAINTENANCE or DIAGNOSTICS section of
this manual.
3. Make sure “POWER” LED is lit. If not, check voltage at secondary side of the main power
transformer. Voltage should be 24-28 VAC. No or low voltage is an indication of a problem with the
supply voltage or transformer. Verify supply voltage and make sure it is the same as voltage rating
on humidifier nameplate. Check secondary power fuses. Make sure that the emergency stop is
rotated outwards.
4. Checkthevoltagetothefillvalve.Voltageshouldbe24-28VAC(voltageshouldbetakenwith 
 wiresconnected).Ifvoltageispresent,fillvalvesolenoidcoilisprobablydefective.Coilresistance
should be 18W(8.3WforHC-6500/6700)withwiresdisconnected.
5. Check for water in cabinet bottom or in fill cup overflow line. If present, see “Water in bottom of
cabinet” on page 26.
6. If no voltage is present to fill valve, check water level. If it is above 2/3 full in level canister, the
drain valve has to open to drain water below high water level before the fill valve is energized.
7. Checkfor24-28Vacpowertodrainvalve(voltageshouldbetakenwithwiresconnected).Ifpower
to drain valve is OK, check drain valve coil resistance with wires disconnected. It should be
approximately 10W(8.3W HC-6500/6700).
