Installation
HC-6100/6300 Mounting
The HumidiClean models HC-6100/6300 are designed to be wall mounted. A wall mounting bracket
andlagscrewsareprovidedformountingon410mm(16”)centers.Theoperatingweightoftheunit
is106kg(233lbs).Aclearanceof600mm(23”)onthefrontandsidesofthecabinetisrequiredfor
servicing.
1. Position wall mounting bracket level on wall and mark hole pattern. Make sure holes line up with
studs or other sturdy structure.
2. Use 3/8” x 1-1/2” lag screws provided to secure the bracket.
3. Hangthehumidifieronthewallmountingbracket.Thedryweightoftheunitis70kg(154lbs).
HC-6500/6700 Mounting
The HC-6500/6700 HumidiClean is designed to be floor mounted on a level surface. The operating
weightis230kg(507lbs),aclearanceof610mm(24”)isrequiredforthefrontandsides.
Water Fill Supply
The humidifier can use any potable or purified water supply. Water pressure must be 25-120 psig.
Watertemperaturemustbelessthan60°C(140°F).Thefillrateis.31GPMforHC6100/6300and1.2
GPM for HC6500/6700 units.
1. Install a shut-off valve near the unit.
2. Connect the water supply to the 3/8” compression fitting on the fill water solenoid valve on models
HC-6100/6300. The HC6500/6700 is supplied with a compression fitting for 10mm plastic tubing. A
6’ piece of 10mm plastic tubing is included for the larger models. The access for the water
supply tubing is under the fill valve in the bottom wall.
Electrical Service Wiring
1. Connect main power supply wiring to high voltage terminals in unit. Read breaker size required on
humidifier’snameplateandrefertoTable7-1and7-2forHC-6100/6300wire(gage)required;
Table 7-1, 7-3 and 7-4 for HC-6500/6700. Make sure an interlocking circuit breaker or safety
 switch(notfurnished)isaccessibleandwithinsightoftheunit.
2. The humidifier cabinet must be grounded. A ground lug is provided in the cabinet.
3.Useonlywirewithcopperconductorsratedat90°C(194°F)orhigherforpowersupplyand 
grounding.
