Display Menu
The menu can be accessed via the keypad below the LCD, on the front of electric cabinet. Use the UP
orDOWNtochangethemenuincurrentlevel;pressESCtopreviousmenulevel;pressENTERto
accessthecurrentmenu.PressingENTERwillactivateselectioncursor,pressUP(DOWN)toincrease
(decrease)thevalue,pressENTERtoconfirmthechangeorESCtocancel.
Run Menu
Language
Unit Status
Armstrong HC-6000 Enter to get into main menu
This screen will only display for 1 minute after the unit is
powered up; then it will automatically go to ‘Unit Status’.
Language Language select
Unit Status Unit status display
Operation Setup Operation variable setup
Unit Configuration Unit configuration setup
English English - Default
Chinese
Unit Status 1
Unit Deamnd: XXX% Demand
Steam Output: XXX lb/hr Steam Output
Unit Status 2
Water Level: Normal Water Level State: Low, Normal and High
Gen, Fill, Drain Idle = No demand; unit idle
Gen = Steam Generation
Fill = Filling
Drain = Draining
Heat = Elements are energized to heat water selected
aquastat setting
Temperature
Water TEMP: XXX C/XXX F Temperature of water
Heat TEMP: XXX C/XXX F Temperature of heating elements
Timers
EOL-TMR: 0000:00 (Default) (End of Life - Ionic Bed Timer based on steam output.)
RUNTIME: 0000:00 (Time that unit has been powered on.)
DRAIN-TMR: 0000:00 (Actual steam generation timer based on output.)
ONTIME: 0000:00 (Drain valve on time after a cycle drain start.)
OFFTIME: 0000:00 (Time that unit sits idle.)
RH Display
Room Current RH: XX% (This menu will be displayed only when “RH Sensor” is selected.)
Room Current RH: XX% (Default)
Room Desired RH: XX%
Duct Current RH: XX% (Only visible if High Limit Sensor is used.)
High Limit Setpoint: XX% (Only visible if High Limit Sensor is used.)
Outside Temperature: XX% (Only visible if Outside Temperature Sensor is used.)
