Setpoints - Explained
Example 1
The setpoint is the required outlet water temperature. The values in the Setpoints tab control the range in
which the setpoint can be adjusted to, but not the current setpoint itself. The Default value is the temperature
the DRV will return to should the power be lost and the DRV80 is reset. The Default is adjustable, but cannot
be more than the Max. (maximum) value or less than the Min. (minimum) value.
Temp 42˚C
Temp 42˚C
normal operation
reset after power failure
(to change back to 43°C use Adjusted Setpoint)
