Important!
The Error Temp value cannot be set lower than the Max value plus the Above Setpoint value.
Note! Adjusted Setpoint value does not need to be the same as the Default value. Both Adjusted Setpoint
and Default can be set within the Max and Min range only.
M
I
X
E
D
T
E
M
P
E
R
A
T
U
R
E
F
L
U
C
T
U
A
T
I
O
N
Max.
Hot
Cold
ALERT
ALERT
SHUT DOWN TO
FULL COLD
45°C
(2°C Above Setpoint)
41°C (2°C Below Setpoint)
38°C
49°C
70°C Error Temp.
Min.
Setpoint
43°C Setpoint
Example 2
