Indicator Lights for the DG860P2
The Touchstone Data Gateway has nine LED indicator lights to assist in trouble -
shooting.
Patterns: Normal Operation (LAN)
The following table shows light patterns for the Ethernet and wireless LANs during
normal operation.
Mode Ethernet WiFi
AC Power
On = Computer
Connected
Off = Computer
not connected
Flash = Com-
puter Activity
On = WiFi
Enabled
Off = WiFi
Disabled
Flash =
Computer Activity
No AC Power Off Off
Firmware Upgrade (normal operation) (normal operation)
Touchstone DG860P2 Data Gateway User’s Guide
Safety
Getting
Started Installation
Ethernet
Configuration Usage Troubleshooting Glossary
37
DG860
Power
Ethernet
DS
Online
WiFi
Secure
US
Power
DS
US
Online
Ethernet
WiFi
Secure
