Y1-03-0273 Rev. D A3-06-2825 Handheld Test Set Operations Manual
Company Confidential Page 20
6. ELT Test Set Unit
The base unit is an Aceeca Meazura MEZ1500 manufactured by Aceeca Ltd of
Christchurch, NZ. The Meazura unit is ruggedized and waterproof to IP67 standards, is
based on the Palm OS version 5.4, and features a long life battery. The ELT Test Set
module plugs into the internal Aceeca MZIO slot and is secured with 2 screws – DO
NOT REMOVE – DOING SO WILL VOID THE ARTEX WARRANTY.
Additional operating information can be found in the Aceeca documents MEZ1500 Quick
Reference User Guide and MEZ1500 HotSync Configuration Guide located on Aceeca’s
website at www.aceeca.com.
6.1 Meazura MEZ1500 Specifications:
Operating System: Palm OS 5.4
Memory: 64MB SDRAM, 128MB Flash
Display: 240x320 color, backlit LED
Communications: USB (cable provided)
SD Card for memory storage (accessory)
Serial (921.6Kbs)
Battery: 7.4V Li-Ion 1700mAh
Sealing: IP67 – submersible to 1 meter (30 min)
Current Consumption: 60-120mA (depending on screen brightness) unit
ON (excluding module) 120mA typical (maximum
brightness).
5 mA Sleep mode
Contact Aceeca at www.aceeca.com for more information on the base Aceeca Meazura
unit or for additional accessories.
6.2 ETS Module Specifications:
406 receiver range: -60dBm to +36dBm (5W)
Power source: Meazura internal battery
Decoding: per COSPAS/SARSAT C/S T.001
Issue 3 Rev. 5
Current Consumption 10mA unit ON
<100nA Sleep mode
6.3 Calibration
The ETS is factory calibrated and does not require periodic re-calibration.
