Arthrex NanoScope User Manual

Electromagnetic Emissions
NanoScope Manual
DFU-0298-1, Revision 0 Page 35 of 38
Table 13 Guidance and Manufacturer's Statement - Electromagnetic Immunity
The NanoScope System is intended for use in the electromagnetic environment
specified below. The customer or the user of the NanoScope System should ensure
that it is used in such an environment.
Immunity test IEC 60601 test
level
Compliance level Electromagnetic environment -
guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
± 8 kV contact
± 15 kV air
± 8 kV contact
± 15 kV air
Floors should be wood,
concrete or ceramic tile. If
floors are covered with
synthetic material, the relative
humidity should be at least
30%.
Electrical fast
transient/burst
IEC 61000-4-4
± 2 kV for
power supply
lines, 100 kHz
± 1 kV for
input/output
lines, 100 kHz
± 2 kV for power
supply lines,
100kHz ± 1 kV
for input/output
lines, 100 kHz
Mains power quality should be
that of a doctor’s office, typical
commercial or hospital
environment.
Surge
IEC 61000-4-5
± 1 kV line(s) to
line(s)
± 2 kV line(s) to
earth
± 1 kV line(s) to
line(s)
± 2 kV line(s) to
earth
Mains power quality should be
that of a doctor’s office, typical
commercial or hospital
environment.
Voltage dips,
short
interruptions
and voltage
variations on
power supply
input lines
IEC 61000-4-11
<5 % Uτ
(>95 % dip in
Uτ)
for 0.5 cycle
40% Uτ
(60 % dip in
Uτ)
for 5 cycles
70% Uτ
(30 % dip in
Uτ)
for 25 cycles
<5 % Uτ
(>95 % dip in
Uτ) for 5 s
<5 % Uτ
(>95 % dip in
Uτ)
for 0,5 cycle
40 % Uτ
(60 % dip in Uτ)
for 5 cycles
70 % Uτ
(30 % dip in Uτ)
for 25 cycles
<5 % Uτ
(>95 % dip in
Uτ)
for 5 s
Mains power quality should be
that of a doctor’s office, typical
commercial or hospital
environment.
If the NanoScope System
requires continued operation
during power mains
interruptions, it is
recommended that the
NanoScope System be powered
from an uninterruptible power
supply.
