Product Specifications
Chapter C
36 Aruba AP-60/61 0510160-03
Installation Guide April 2008
Physical
(HxWxD):
z Antenna up, stand closed—216 x 99 x 31 mm /
8.50 x 3.90 x 1.22 in
a
z Antenna up, stand open—209 x 99 x 74 mm /
8.23 x 3.90 x 2.91 in
z Antenna 90
o
, stand closed— 159 x 99 x 71 mm /
6.26 x 3.90 x 2.80 in
z Weight 255 grams / 9 oz
Interfaces
(Electrical):
z 1 x 10/100 Base-TX auto-sensing Ethernet
RJ-45 Interface (Auto-sensing MDI/MDX)
z Serial and Power Over Ethernet - 48 VDC/200
mA Power Over Ethernet (802.3af compliant)
z 1 x 5V DC Power Interface
Interfaces
(Mechanical):
Standard Kensington MicroSaver Security Cable
Interface (cable not supplied)
Wall and ceiling mount kit (optional - part number
AP-60-MNT) interface
Visual
Indicators
(LEDs)
Ready -- Power
Ethernet link status / Activity
WLAN Activity
Power z Optional AC Power Adapter Input—
100-240 AC, 50-60 Hz
z Access Point Input—
5 VDC, 3 A (AC adapter), or 48 VDC, 200 mA
(POE)
Power
Requirements
z 5 VDC / 2 A supplied externally via optional AC
adapter kit
z 48 VDC / 200 mA Power Over Ethernet (802.3af
compliant)
z Auto-sensing externally supplied AC power or
Power Over Ethernet
Output Power 100 mW maximum (or lower as configured on the
Aruba Mobility Controller to comply with local
regulatory requirements)
Power
Consumption
10W maximum
T
ABLE B-4 AP-61 Characteristics (Continued)
Description
