Aruba AP-60 - Back View

Aruba AP-60/61 5
Installation Guide
Introduction
Chapter 1
Back View
FIGURE 1-2 Aruba AP-60/61 Back View
Mounting Slots
The keyhole-shaped slots on the back of the chassis are used for mounting the
Aruba AP-60/61.
Air Vents
These vents promote proper air circulation for cooling the device. Do not allow
these vents to be obstructed by mounting equipment, network cables, or any
other material.
1
3
2
4
1
2
