Aruba AP-85 Outdoor Access Point Series | Installation Guide AP-85 Series Hardware Overview | 9
Hardware Model Overview
AP-85 Series Front View
The front of the AP-85 Series has LED status indicators (see Figure 1). For descriptions of the LEDs and their behavior, refer
to "LED Status Indicators" on page13.
Figure 1 AP-85 Series Front View
AP-85 Series Rear View
The rear of the AP-85 Series has four mounting holes (see Figure 2). Refer to Chapter 3, “AP-85 Series Installation” on
page 21 for mounting and installation instructions.
Figure 2 AP-85 Series Rear View
