Installation and Getting Started | Installation and Getting Started Guide 7
Figure 6 R8R46A rear
Item Description
1 1GbE RJ45 ports Link/Status LED per port
2 Global Status LED
3 PoE Max LED
4
PoE Status LED per port
5 8 x 1GbE RJ45 & PoE ports
Figure 7 R8R47A
Item Description
1 PoE & 1GbE RJ45 ports Link/Status LED per port
2 PoE Status LED per port
3 16 x 1GbE RJ45 & PoE ports
4
Global Status LED
5 PoE Max LED

Aruba Instant On 1430 Specifications

General

Model	Aruba Instant On 1430
Category	Switch
Management	Unmanaged
Layer	Layer 2
Jumbo Frame Support	Yes
Quality of Service (QoS)	Yes
Cloud Management	No
Ports	24
RJ-45 Ports	24
Mounting	Desktop
Power Consumption	Varies by model
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 40°C (32°F to 104°F)
Operating Humidity	15% to 95%
Power Supply	External
Forwarding Rate	38.7 Mpps
