Operation
34 1590 99 002_1 - 21. February 2011
The change to the Treatment screen via Indication list is only possible, if the correct handpiece has
been connected. If no handpiece or the wrong one is connected, a corresponding message will be
displayed.
You have several options to change from the main menu to the Treatment screen:
Start via Quickstart
(User-selected parameters can be directly set on the display according to the selected mode
Basic, Professional, SmoothPulse, Burst or Vascular.)
Start via Indication list
(According to the selected indication, appropriate parameters are already displayed for the
test treatment. Depending on the reaction to the test treatment they are to be reduced or
increased. See chapter 6 .)
Start via Patient database
(This option is recommended for continuing a treatment.)
5.6.1 Start via Quickstart
To display the screen, press the key in the main menu. The system needs few
seconds to open this window.
Via the Quickstart menu ( : Quickstart screen, example mode) you can start your laser
device.
Figure 28: Quickstart screen
Refer to chapter Fehler! Verweisquelle konnte nicht gefunden werden. Fehler! Verweisquelle konnte
nicht gefunden werden. for setting the parameters
On the display in the Quickstart menu you can also select the different modes Basic, Professional,
Smooth Pulse, Burst and Vascular apart from the parameters, if they are released for the
connected handpiece. (See 6 for application instructions.)
