ASCOM IP-DECT IPBS2 User Manual

TD 92989EN
15 October 2014 / Ver. B
Installation Guide
IP-DECT Base Station & IP-DECT Gateway
5
2.2 IPBS2
The following versions of the IPBS2 are available:
• IPBS2 with internal antenna
• IPBS2 with external antennas
The IPBS2 is backward compatible with the IPBS1 when it comes to coverage,
functionality, accessories and mounting bracket. If an old IPBS1 has to be replaced you just
reuse the mounting bracket and install the IPBS2.
2.2.1 IPBS2 with Internal Antenna
Figure 2. IPBS2 Overview
Contents of the Box
The box in which the IPBS2 is packed contains:
• An IPBS2 with integrated antennas
• A mounting bracket
• Two screws with wall plugs
Front view
LED
LAN
(RJ45)
Power Supply
(RJ45)
Back view while lying down
Used for cable ties
to provide strain
relief for cables
Back view
Reset
