7. PROGRAMMABLE PARAMETERS TABLE
Here below is a description of all the parameters available
on the instrument. Some of them may not be present, either
due to the fact they depend on the type of instrument or be-
cause they are automatically disabled as unnecessary.
Parameter Description Range Def. Note
1
SLS
Minimum Set Point -99.9 ÷ HS -50.0
2
SHS
Maximum Set Point LS ÷ 999 99.9
3
SP
Set Point LS ÷ HS 0.0
4
SPE
Set Point Eco SP ÷ SHS 0.0
5
iuP
Unit of measurement and
resolution (decimal point)
C0 °C, resolution 1°;
F0 °F, resolution 1°;
C1 °C, resolution 0.1°;
F1 °F, resolution 0.1°.
C1
6
iFt
Measurement filter
oF Filter disabled;
0.1 ÷ 20.0 s
2.0
7
iC1
Pr1 Probe Calibration -30.0 ÷ +30.0°C/°F 0.0
8
iC2
Pr2 Probe Calibration -30.0 ÷ +30.0°C/°F 0.0
9
iCU
Display offset -30.0 ÷ +30.0°C/°F 0.0
10
iP2
Input Pr2 usage
oF Unused;
EP Do not use;
Au Auxliary probe;
dG Digital Input.
dG
11
iFi
Function and logic function-
ing of the Digital Input
(adding the “-” minus sign
the logic is inverted)
0 No function;
1, 2 Open Door;
3 Open Door with Output Lock;
4 External Alarm;
5 External alarm with output disabling;
6 Normal/Eco select;
7 On/Stand by select;
8 Do not use;
9 Defrost cycle start;
10 Defrost cycle end.
0
12
iti
Digital Input Delay
oF Disabled;
-1 ÷ -59 (s) ÷ 1 ÷ 99 (min).
oF
13
iEt
Eco Mode activation delay
at Door closed
oF Disabled;
-1 ÷ -59 (min) ÷ 1 ÷ 99 (h).
oF
14
itt
Max. time functioning in
Eco Mode
oF Disabled;
-1 ÷ -59 (min) ÷ 1 ÷ 99 (h).
oF
15
idS
Variable normally displayed
P1 Probe Pr1 measure;
P2 Probe Pr2 measure;
P3 Do not use;
Ec Measure Pr1 in Normal mode
+ ECO label when in ECO mode;
SP Set Point;
oF Display not lit.
P1
16
rd
Differential (Hysteresis) 0.0 ÷ 30.0°C/°F 2.0
17
rEd
Differential (Hysteresis) in
ECO mode
0.0 ÷ 30.0°C/°F 2.0
18
rt1
Output activation time for
Pr1 probe error
oF Disabled;
-1 ÷ -59 (s) ÷ 1 ÷ 99 (min).
oF
19
rt2
Output deactivation time
for Pr1 probe error
oF Disabled;
-1 ÷ -59 (s) ÷ 1 ÷ 99 (min).
oF
20
rHC
Output operating mode
H Heating;
C Cooling;
nr Do not use;
HC Do not use;
C3 Do not use.
C
21
ddL
Display Lock during defrost
oF Not active;
on Active at last measure;
Lb Active with label
dEF during defrost and
PdF at defrost.
oF
22
dcd
Defrost activation time for
continuous compressor
operating
oF Disabled;
-1 ÷ -59 (min) ÷ 1 ÷ 99 (h).
oF
23
dde
Defrost duration
oF Disabled;
-1 ÷ -59 (min) ÷ 1 ÷ 99 (h).
oF
24
ddi
Defrosting interval
oF Disabled;
-1 ÷ -59 (s) ÷ 1 ÷ 99 (min).
oF
25
dSd
Delay first defrost after
power-on
oF Defrost at power-on;
-1 ÷ -59 (min) ÷ 1 ÷ 99 (h).
oF
26
PP1
Out delay at switching-on
oF Disabled;
-1 ÷ -59 (s) ÷ 1 ÷ 99 (min).
oF
27
PP2
Out delay after switch-
ing OFF
oF Disabled;
-1 ÷ -59 (s) ÷ 1 ÷ 99 (min).
oF
28
PP3
Delay between two output
switching-ON
oF Disabled;
-1 ÷ -59 (s) ÷ 1 ÷ 99 (min).
oF
Parameter Description Range Def. Note
29
Pod
Output delay at power ON
oF Disabled;
-1 ÷ -59 (s) ÷ 1 ÷ 99 (min).
oF
30
AAy
Temperature Alarm 1 type
1 Absolute for Pr1 with label Hi - Lo;
2 Relative to Pr1 with label Hi - Lo ;
3 Absolute for Au with label Hi - Lo ;
4 Relative to Au with label Hi - Lo ;
5 Absolute for Pr1 with no label;
6 Relative to Pr1 with no label;
7 Absolute for Au with no label;
8 Relative to Au with no label .
1
31
AHA
High temperature Alarm
threshold
oF Disabled;
-99.9 ÷ +999°C/°F.
oF
32
ALA
Low temperature Alarm
threshold
oF Disabled;
-99.9 ÷ +999°C/°F
oF
33
AAd
Temperature Alarms
Differential
0.0 ÷ 30.0°C/°F 1.0
34
AAt
Temperature Alarms Delay
oF Disabled;
-1 ÷ -59 (s) ÷ 1 ÷ 99 (min).
oF
35
APA
Temperature Alarms delay
at power ON
oF Disabled;
-1 ÷ -59 (min) ÷ 1 ÷ 99 (h).
2.00
36
AdA
Temperature Alarms delay
and unlock display delay
after defrost
oF Disabled;
-1 ÷ -59 (min) ÷ 1 ÷ 99 (h).
1.00
37
AoA
Open Door Alarm Delay
oF Disabled;
-1 ÷ -59 (s) ÷ 1 ÷ 99 (min).
3.00
38
obu
Buzzer function mode
oF Function disabled;
1 Active for alarms only;
2 Active for key pressed only;
3 Active for alarms and key pressed.
3.00
39
tUF
/ Key Function
oF No function;
1 Do not use;
2 ECO Mode selection;
3 Switch ON/Switch OFF (Stand-by);
4 Do not use.
oF
40
tFb
/Aux Key Function
oF
41
tLo
Keyboard lock function
delay
oF Disabled;
-1 ÷ -59 (s) ÷ 1 ÷ 30 (min).
oF
42
tEd
Set Point visibility with
key fast procedure
0 None;
1 SP;
2 SPE;
3 SP and SPE;
4 Active SP;
5, 6 Do not use.
1
43
tPP
Password to Access
Parameter functions
oF Disabled;
001 ÷ 999.
oF
