Ascon tecnologic TLY25 User Manual

Group
]
dEF (parameters relative to defrosting control)
Par. Description Range Def. Note
19 dtyP Defrosting Type:
EL = electrical
in = hot gas/reverse
cycle
EL - in EL
20 dint Defrosting interval OFF ÷ 99.59
hrs.min
6.00
21 dF 1 Time start defrost 1 OFF - 00.00 ÷
23.59 hrs.min
OFF
22 dF 2 Time start defrost 2 OFF - 00.00 ÷
23.59 hrs.min
OFF
23 dF 3 Time start defrost 3 OFF - 00.00 ÷
23.59 hrs.min
OFF
24 dF 4 Time start defrost 4 OFF - 00.00 ÷
23.59 hrs.min
OFF
25 dF 5 Time start defrost 5 OFF - 00.00 ÷
23.59 hrs.min
OFF
26 dF 6 Time start defrost 6 OFF - 00.00 ÷
23.59 hrs.min
OFF
27 dEFE Max. lenght of defrost
cycle
0.01 ÷ 99.59
min.sec
30.00
28 tEdF Defrost stop
temperature
- 58 ÷ 302
°C/°F
8.0
29 tSdF Defrost enable
temperature
- 58 ÷ 302
°C/°F
2.0
30 dCt Defrosting intervals
Counting mode:
rt = real time
ct = On OUT time
cS = defrost every off
OUT
rt - ct - cS rt
31 tdCO Compressor delay after
defrost (drainage time)
OFF ÷ 99.59
min.sec
OFF
32 SdEF Defrost at power on no - yES no
33 dLo Defrost display
LockOFF= display
freeOn= Lock on
temperature Pr1 before
defrostLb= Lock on
label “dEF” (during
defrosting) and “PdEF”
(during post-defrosting)
On - OFF - Lb OFF
34 Etdu Differential display
unlock after defrost
0 ÷ 30
°C/°F
2.0
35 COFd Time compressor off
before defrost
OFF ÷ 99.59
min.sec
OFF
Group
]
FAn (parameters relative to evaporator fan control)
Par. Description Range Def. Note
36 FCOF Fan status with
compressor off
On - OFF On
37 FEdF Fan status during defrost On - OFF OFF
38 FLt High temperature fan
off
- 58 ÷ 302
°C/°F
2.0
39 Fct Low temperature fan off - 58 ÷ 302
°C/°F
-50.0
40 dF Differential fan control 0 ÷ 30
°C/°F
2.0
41 Fd Fan delay after defrost OFF ÷ 99.59
min.sec
OFF
Group
]
PrC (parameters relative to compressor protection and
power on delay)
Par. Description Range Def. Note
42 PSC Type of compressor
protection:
1= delay at switch on
2= delay after switch off
3= delay between starts
1 - 2 - 3 1
43 PtC Compressor protection
time
OFF ÷ 99.59
min.sec
OFF
44 LtC Minimum compressor OFF ÷ 99.59 OFF
function time min.sec
45 od Delay at power on OFF ÷ 99.59
min.sec
OFF
Group
]
AL (parameters relative to alarms)
Par. Description Range Def. Note
46 Aty Temperature alarms
Type:
Ab = Absolute
dE =Relative to Set
Ab - dE Ab
47 HAL High temperature Alarm
threshold
OFF / - 58 ÷
302 °C/°F
OFF
48 LAL Low temperature Alarm
threshold
OFF / - 58 ÷
302 °C/°F
OFF
49 dAL Temperature Alarms
Differential
0 ÷ 30
°C/°F
2.0
50 ALd Temperature Alarms
delay
OFF ÷ 99.59
min.sec
OFF
51 tAL Alarm memory no - yES no
52 PAL Temperature Alarms
delay at power on
OFF ÷ 99.59
hrs.min
2.00
53 dALd Temperature Alarms
delay and unlock
display delay after
defrost
OFF ÷ 99.59
hrs.min
1.00
54 dALc Temperature alarms
delay after continuous
cycle
OFF ÷ 99.59
hrs.min
OFF
55 oAd Alarm delay with open
door
OFF ÷ 99.59
min.sec
OFF
Group
]
din (parameters relative to digital input)
Par. Description Range Def. Note
56 diF Function and function
logic of digital input:
0 = No function
1= Start defrost
2= End defrost
3= Continuous cycle
4= External alarm
5= Door open with fan
block
6= Door open with fan
and compressor block
7= Auxiliary output
command
8= Selection of active
Set Point
9= External alarm with
deactivation of control
outputs
10= Switch on/Switch
off (Stand-by)
-10 / -9 / -8 / -
7 / -6 / -5 / -
4 / -3 / -2 / -
1 / 0 / 1 / 2 / 3
/ 4 / 5 / 6 / 7 /
8 / 9 / 10
0
57 did Delay in acquiring
digital input
OFF ÷ 99.59
min.sec
OFF
Group
]
AuS (parameters relative to auxiliary output)
Par. Description Range Def. Note
58 FOA Function mode auxiliary
output:
0= No Function
1= regulation output
delayed
2= manual activation by
key or digital input.
0 / 1 / 2 0
59 tuA Time relative to
auxiliary output
OFF ÷ 99.59
min.sec
OFF
Group
]
Out (parameters relative to configuration of outputs)
Par. Description Range Def. Note
60 Out1 Configuration of output
function OUT1:
OFF= No function
Out= Temperature
control (compressor)
OFF/Out/dEF/
FAn/AuS/ALt/
AL/ALL/ -ALt/
-AL/ -ALL
Out
Ascon Tecnologic - TLY25 - OPERATING INSTRUCTIONS - PAG. 9
