ASEA AC25QTP-1 - Specifications; Electrical Specifications

AC25/30QTP-1 and -3 Operations Manual.... 12
4 SPECIFICATIONS
4.1 ELECTRICAL SPECIFICATIONS
4.1.1 Input Service
Table 1: Input Specifications
Parameter AC25-1, -3 AC30-1, -3
Input Power Form Single or Three Phase Single or Three Phase
Input Voltage Range 170-520 Vrms 170-520 Vrms
Input Frequency Range 40-70 Hertz 40-70 Hertz
Max. Input Current
Single Phase 105 Arms 125 Arms
Three Phase 70 Arms 83 Arms
Max. Soft-Start Input Current 20 Arms 20 Arms
Input Current Distortion <5% THD @ rated load <5% THD @ rated load
Input Power Factor >0.99 @ rated load >0.99 @ rated load
4.1.2 Output Service
Table 2: Output Specifications
Parameter AC25-1, -3 AC25-1, -3
Output Power Rating 25kVA @ 0.85 p.f. 30kVA @ 0.85 p.f.
Output Power Form Single Phase 220 or 230 Vrms, Split Phase 120/240
Vrms or, Three Phase 120/208, 127/220, 220/380,
230/400, or 240/416
*Note: Minor variations in the above voltage levels can
be accommodated, contact factory for additional
information.
Output Frequency 50 or 60 Hertz 50 or 60 Hertz
Output Frequency Accuracy 0.01% 0.01%
Output Voltage Distortion < 1.5% THD < 1.5% THD
Output Voltage Line Regulation 0.50% 0.50%
Output Voltage Load Regulation 1.0% 1.0%
