AC25/30QTP-1 and -3 Operations Manual.... 14
4 SPECIFICATIONS, cont.
4.1 ELECTRICAL SPECIFICATIONS, cont.
4.1.3 Control, Metering, and Status
Input Power Control Input Service Disconnect Switch, 2 pos.
Shore Power Control Membrane Switch, Input ON/OFF Control
Converter Power Control Membrane Switch, Output ON/OFF Control
Ship’s Power Control Membrane Switch, Generator/Converter Power
Transfer Control
Shore Power Metering Voltage, Current, Frequency, kVA, kW, %Load
Converter Power Metering Voltage, Current, Frequency, kVA, kW, %Load
Generator Power Metering Generator 1 - 4, Voltage, Frequency
System Status Operational status, Diagnostics, Software Calibration
4.2 PHYSICAL SPECIFICATIONS
4.2.1 Mechanical
Table 4: Physical Dimensions
Parameter
AC25QTP-1, -3 AC30QTP-1, -3
Part 1 Part 2 Part 1 Part 2
Height 27.84”/70.7cm 27.84”/70.7cm 27.84”/70.7cm 27.84”/70.7cm
Width 13.75”/34..9cm 13.75”/34..9cm 13.75”/34..9cm 13.75”/34..9cm
Depth 26.35”/66.9cm 26.35”/66.9cm 26.35”/66.9cm 26.35”/66.9cm
Weight 204lb/92.7kg 346lb/157.3kg 204lb/92.7kg 346lb/157.3kg
4.2.2 Environmental
Ambient Temperature Range 0-50C non-condensing
Air Exchange Rate 800 CFM (ft
3
/min) / 1360 m
3
/hour
