AC25/30QTP-1 and -3 Operations Manual.... 20
5.2 ELECTRICAL INSTALLATION
This procedure assumes the physical installation of the converter has been completed.
It is the installer’s responsibility to provide input service over-current protection and a
disconnect means.
It is recommended that connection be made to the distribution bus through a manually operated
disconnect device such as a molded case switch or circuit breaker (rated for the total system
amperage) to ease disconnection and provide a safe servicing environment in the event of
converter failure.
Follow the table below for shore power wiring.
Table 6: Input Service Over-Current Protection Specifications
Maximum Currents Under Low-Line Conditions
Input Current
AC25-1, -3 AC30-1, -3
Single Phase, 330-520V 155A 155A
Three Phase, 170-290V 78A 78A
Three Phase, 170-290V 89A 89A
Output Current
Refer to Table 3
All power wiring requires the removal of the front panel and the power cable access cover
(cabinet bottom). This cover is secured with 2 ea 1/4-20" x ½" stainless steel screws. Drill or
punch the appropriate holes for the selected strain reliefs. Re-install the input service panel using
the removed hardware. Place the disconnect switch in the OFF position.
