Set the Pan Positions
Osc 1-3 Pan
To set the stereo placement of the oscillators,
access [MIXER] and use the Page Down arrow to
select page 3. Control knobs 1-3 contain the pan
positions for Oscillators 1-3. Use the appropriate
Control knob to adjust the pan position of
each item, and use [SHIFT] + Control knob X to
ne-tune the value.
Ring + Noise Pan
To set the stereo placement of the Ring modulator
and Noise generator, access [MIXER] and use the
Page Down arrow to select page 4. Control knobs
1 and 2 contain the parameters Ring Pan and Noiz
Pan, respectively. Use the appropriate Control
knob to adjust the pan position of each item, and
use [SHIFT] + Control knob X to ne-tune the
value.
Mixer parameters: pages 5-6
Page Control Parameter Range Description
5 1 Osc1Filt 100:0 - 0:100 Ratio of Osc 1 fed to the two lters
5 2 Osc2Filt 100:0 - 0:100 Ratio of Osc 2 fed to the two lters
5 3 Osc3Filt 100:0 - 0:100 Ratio of Osc 3 fed to the two lters
5 4 Filter Routing Series, Parallel Places the lters in Series or Parallel conguration [1]
6 1 Ring Filt 100:0 - 0:100 Ratio of Ring mod fed to the two lters
6 2 Noise Filt 100:0 - 0:100 Ratio of Noise source fed to the two lters
6 4 Filter Routing Series, Parallel Places the lters in Series or Parallel conguration [1]
[1] Pages 5 and 6 share this parameter with Filter 1 page 3; changing one also changes the other.
Filter Routing of Sources
Osc 1-3 Filter routing
To adjust the routing of each oscillator between
Filter 1 and Filter 2, access [MIXER] and use the
Page Down arrow to select page 5. Control knobs
1-3 contain the lter routing values for Oscillators
1-3. Use the appropriate Control knob to adjust
the lter routing of each item:
• 100:0 sends the source only to Filter 1.
• 0:100 sends the source only to Filter 2.
• Intermediate values send the source to both
lters in varying amounts.
Use [SHIFT] + Control knob X to ne-tune the
values. Control knob 4 sets the Filter conguration
(see below).
Ring + Noise Filter routing
To adjust the routing of the Ring modulator and
Noise generator between Filter 1 and Filter 2,
access the [MIXER] module. Hold [SHIFT] and press
the Page Down arrow to jump to page 6. Control
knobs 1 and 2 contain the parameters RingFilt
and NoizFilt. Use the appropriate Control knob to
adjust the lter routing of each item:
• 100:0 sends the source only to Filter 1.
• 0:100 sends the source only to Filter 2.
• Intermediate values send the source to both
lters in varying amounts.
Use [SHIFT] + Control knob X to ne-tune the
values.
Filter Conguration
This setting species whether the lters operate in Series or Parallel mode. When they are in Series,
Filter 1 always passes through Filter 2. When they are in Parallel, sources can be routed so they pass
through only one of the lters or through both lters in varying amounts (as described above in Filter
Routing of Sources (p. 32)).
Pages 5 and 6 share this parameter with Filter 1 page 3, edit eld 1; changing one also changes the
other.
