SPECIFICATIONS
Physical
Dimensions: 55.4 x 24.7 x 5.8 cm (21.81 x 9.72 x 2.28 inches)
Weight (without batteries): 3.46 kg (7.63 lbs)
Connections: Rear Panel
• MIDI In/Out
• USB type B port, class-compliant
• Headphone output
• Impedance: 16 – 75 Ohm
• Stereo 1/4” outputs (balanced)
• Sustain pedal input (polarity-sensing)
• CV/Gate/Clock outputs: Five (1/8” TS)
• Pitch • Gate • Mod 1 • Mod 2 • Clock
• Power:
• 12 V DC, ≥1A (Center: positive)
• 8 x AA batteries (optional): Alkaline or
Ni-MH
CV/Gate/Clock outputs:
Control Voltages
• Range: -5V to 5V
• Pitch: + / - 99 cents
• Mod: + / - 3.0V
• Standards: 1V / octave,
1.2V / octave, Hz/Volt
Gate Output
• Range: 3V, 5V
• Type: V-trig, S-trig
Clock Output
• Range: 3V, 5V
• Rates: 1 PPS, 2PPQ, 24 PPQ, 48PPQ
• Oset: + / - 100ms
• Division: 1/2x, 2x, 4x
