ASROCK M8 - Page 31

26
English
2. Remove the ODD+2.5" HDD Tray.
3
2
2
2
1
Unplug the ODD SATA power connector.
Remove the ve screws securing the ODD + 2.5" HDD Tray to the chassis.
Li the tray o the chassis.
3. Place a 2.5" HDD to the HDD tray and secure the hard drive using the four screws (four
in the rear).
1
2
3
