English
5
2.2 Detaching the Stand Arm and Base
Before removing the stand, be sure to turn off the monitor and disconnect all cables.
1. Push the stand lock to the unlock position. Lift upward to disengage the tabs on the
stand arm from the monitor. Remove the stand (arm and base).
A
B
UNLOCK
2. Release the screw at the bottom of the stand base. Pull to remove the stand base
from the stand arm.
B
A
To Next Page
