10
AH20 Advanced Wiegand (J100) - Connections
AH20 Advanced Wiegand Connectors (J100)
relay ContaCts DesCription
NCL Normally Closed
COM
Common
NOP Normally Open
NCL1
COM1
1 2 3 4
NOP1
NCL2
COM2
NOP2
NCL3
COM3
NOP3
NCL4
COM4
NOP4
A
A0
A1
A2
A3
A4
EXT
INT
TERM
B
D1
D0
RED
GREEN
GND
8-24VDC
J101
J100
S700
S100
ON
OFF12345678
relays DesCription
Relay 1 DPS (Door Position)
Relay 2 RX (Request to exit)
Relay 3 Battery Alarm Output
Relay 4
Tamper Alarm Output/
Lock Jammed
