Assa Abloy Aperio AH30 - 4 Mechanical Installation; Mechanical installation AH15; Installation examples for AH15 communication hub with E-cylinder locks; Installation examples for AH15 communication hub with other type of locks

7
1
3
2
AH40 - Mounting, Bottom Cover
Bottom Cover
Top Cover
External
Antenna
Option
Screw
(4 x 35 mm)
Screw
(3 x 10 mm)
AH20/30 - Mounting, Bottom Cover (EU version)
