Assa Abloy Aperio AH30 Installation Guide

15
aDDress a0 a1 a2 a3 a4*
0 Pairing Active*
1 ON
2 ON
3 ON ON
4 ON
5 ON ON
6 ON ON
7 ON ON ON
8 ON
9 ON ON
10 ON ON
11 ON ON ON
12 ON ON
13 ON ON ON
14 ON ON ON
15 ON ON ON ON
Address examples
*) Note: If any of the A0-A4 DIP switches are moved from OFF to ON
within 10 seconds from boot up and the Hub LED is lit, all paired
devices will be unpaired.
AH30 - RS485 Addressing
