Assa Abloy Aperio AH30 Installation Guide

13
Dip
switCH
number
label DesCription
1-5 A0-A4
Controls RS485 addressing BIT 0-BIT 4.
ON => Address bit set.
OFF => Address bit NOT set.
See AH30 - RS485 Addressing Reference on page 13.
6-7 TERM
Control use of termination resistor between RS485 A
and RS485 B.
For termination to be enabled, both switches must
be set to ON.
ON =>120 Ohm termination resistor connected/
enabled.
OFF => 120 Ohm termination resistor disconnected/
disabled.
8 INT/EXT
Controls use of external antenna if required.
ON =>Selects use of internal antenna.
OFF => Selects use of external antenna.
AH30 - DIP Switch Configuration Table (S700)
