Assa Abloy Aperio AH30 Installation Guide

18
Physical Dimensions 82 mm x 82 mm x 37 mm (H x W x T)
Power Supply 8-24 VDC
Power Rating
The power supply shall be able to deliver minimum
2 W (AH20 Advanced) alternatively 0.8 W (AH20
Standard and AH30) and be 3 A over current
protected. Wire requirements 16-22 AWG.
Radio Standard
IEEE 802.15.4 (2400 – 2483,5MHz)
16 channels (11-26)
AES 128 bit encryption
Receiver Sensitivity -100 dBm
Wireless Transmit
Power
10 dBm/MHz. Peak value from average detector
according to EN ETSI 300 328 Maximum spectral
density.
Wireless Operating
Range
Indoors up to 25 m depending upon installed
environment.
Internal Antenna Two cross polarized dipoles.
External Antenna
One reverse polarity SMA external antenna
connector. AH20/30 is certified to be used with
ASSA ABLOY external antenna AH-ANTENNA-1. If
other external antenna is used it must be of same
type (dipole) and not have larger antenna gain than
3.6 dBi.
Operating
Temperature
5 °C to 35 °C.
Humidity < 95 % non-condensing.
IP Classification IP20
Safety, Radio and
EMC
IEC 62368-1:2014
EN 62368-1:2014 + A11:2017
UL/CSA 62368-1:2014
EN 301 489-1 V2.1.1
EN 301 489-17 V3.2.0
EN 300 328 V2.2.2
EN 50130-4:2011 + A1:2014
EN 62311
FCC 47CFR Part 15 subpart B and subpart C
ISED RSS-247 and ICES-003
AS/NZS 4268
AH20/AH30 - Technical Data
