Assa Abloy Aperio Series - Lock Orientation Options; Prepping the Cabinet;Drawer Face

Page 4 of 16 For more information visit website assaabloyesh.com P/N: 3080006.016 Rev1
Lock Orientation Options
Prepping the Cabinet/Drawer Face
1. Separate Strike Plate Template.
2. Establish centerline (for double door
cabinet prep go to page 6).
Orientation A
Orientation B
Orientation C
