Assa Abloy effeff 1383 - Individual Escape Door Module 1385 E1 N

14
Circuit diagram
1)
Connections have different functions depending on the configuration
(see the ‚Configuration‘ section).
Individual es-
cape door mo-
dule
1385E1N
F1
Littelfuse
154001
1AF
2
1
3
4
5
6
7
8
9
11
12
10
13
14
15
16
AB E
D F
S
Data
LB1
LB2
Voltage supply via an
external mains adapter
12 - 24 VDC +15% / -10%
according
to DIN/EN 60950
Connection of the
respective locking
part
SYSCON-5
SYSCON-4
Jumpers LB1/LB2
5-pin system plug connector for
connection of the type 1385ES1
key switch or additional
components
max. 24V / 1A
TS Bus
2 x 4-pin system plug
connector for
connection of the mains
adapter type
1003FT-24-05 and/or
additional system
components
Potential-free
relay contact
1)
Universal
input
1)
+
-
See manual D00470..
