Assa Abloy effeff 1383 - Identification of the Cause of the Alarm

70
gn
gn
gn
gn
 Alarm signal is present.
 Turn the key to the left.
 Alarm is acknowledged.
 Three green LEDs light up.
 The lower right-hand green LED
flashes.

 Turn the key to the left and
hold.
 The cause of the alarm is
indicated by an LED sequence
pattern (see the following
table).
 Eliminate the cause of the
alarm.
Three green LEDs light up and the lower right-hand green LED flashes.
You can also identify the following indicator displays which represent the
cause of the alarm.
Additional indicator displays Cause of alarm
Right-hand yellow LED lights up Centrally operated release
Left-hand yellow LED lights up EMERGENCY-OPEN
Both yellow LEDs above and be-
low light up.
Central EMERGENCY-OPEN
activated
Identification of
the cause of the
alarm
