Assa Abloy effeff 1383 - Key Switch Module; Profile Half Cylinder

72
Electrical data
Identifier Value
Contact rating -
Micro-switch
Max. 24 V/0.1 A (ohmic load)
Safety measure Low safety voltage
Protection system according to DIN/
EN 60529
IP30
Mechanical data
Identifier Value
Operating temperature range -20°C to +40°C
Storage temperature range -20°C to +60°C
Installation dimensions For standard flush-mounted boxes:
62.5 mm deep
Dimensions
Identifier Size
(Centre of mounting screw -
cylinder leading edge)
DIN profile half cylinder 30.5 mm
Lock catch 180°
Identifier Value
Operating temperature range -20°C to +40°C
Storage temperature range -20°C to +60°C
Installation dimensions For standard flush-mounted boxes:
62.5 mm deep
Electrical data
Identifier Value
Contact rating -
Micro-switch
Max. 12 V/0.1 A (ohmic load)
Safety measure Low safety voltage
Protection system according to DIN/
EN 60529
IP30
Key switch
module
Profile half
cylinder
Key switch
module
