26
Configuration using the
1385
DIP switch networked stand-alone
1 Address off
2on
3
Profile number
4
5 off
6 off
7 off
8 Networked operating
mode
= on
Stand-alone operating
mode
= off
Note: A TS bus controller is
required.
The
1385
must be set to
master operation (
1385
:
DIP 3 = on)
Additional information
If configuration is carried out using
FT Manager
, always select Profile
‚0‘ (called functions templates in
FT Manager
) as it is the only place
where changes can be saved.
Profiles when using the
1385
(stand-alone)
Profile DIP switch Function
34
0 off off Link to higher level systems (fac-
tory setting)
1 off on Door drive
2 on off Door control
3 on on Interlock
