What do I have?
What do I need?
1 5000 series strike body
1 Trim enhancer
2 Trim enhancer screws
5-11 Blue wire connectors
quantity
description
item
What tools would you recommend I use?
quantity
description
item
1 5000 series faceplate
2 Faceplate screws
2 Mounting screws
1 Pig tail connector
You will need 1 faceplate option kit (not included, see page 3) which contains:
*
*tool may differ for different applications
#4-40 x 1/8
#8-32 x 5/8
1
2
3
4
5
6
#12-24 x 1/2
2
1
2
3
4
5
6
What item are you looking for?
5000 series strike body
Faceplate option kit
Trim enhancer
Mounting screws
Faceplate screws
Trim enhancer screws
1
2
3
4
5
6
Caution
Before connecting electric strike at the installation site verify input
voltage using a multimeter. Any input voltage exceeding 10% of the
solenoid rating may cause severe damage to the unit.
(sold separately)
(sold with faceplate option kit)
(sold with faceplate option kit)
