Assa Abloy HES 5000 Series User Manual

Raising the Standards
13
14
An ASSA ABLOY Group company
Installer Hint
To obtain the best results, always cut well inside the lines and
use a metal file to finish off the cutout.
3 3/8"
85.7
1 1/4"
31.8
4 7/8"
124
11/16"
17.5
[2.3]
3/32"
What should the cutout be?
Cut frame according to the dimensions in the drawing.
a
a
501 faceplate option
What are the faceplate dimensions?
501 faceplate option
[mm]
Inches
[mm]
Inches
