4 Technical specifications
Ensure that the door operator with technical specification below is suitable for the installation.
ASSA ABLOY Entrance Systems ABManufacturer:
Lodjursgatan 10, SE-261 44 Landskrona, SwedenAddress:
ASSA ABLOY SW300 and ASSA ABLOY SW150Type:
100-240 V AC +10/-15%, 50/60 Hz, mains fuse max 10A (building
installation)
Mains supply:
Note! The mains supply shall be installed with protection and an
all-pole mains switch with isolating capability of Category III, at least
3 mm between contacts, shall be installed according to local regu-
lations. These articles are not provided with the door.
Max. 300 WPower consumption:
24 V DC, max. 700 mA (max. 1000 mA including lock)Auxiliary voltage:
2 x T 6,3 AH/250 VMains fuse F1, F2:
PUSH arm system; size 4 - 7Door size:
PULL arm system; size 4 - 6
For PUSH = 140 kgm
2
for ASSA ABLOY SW300 and
70 kgm
2
for ASSA ABLOY SW150
For PULL = 80 kgm
2
for ASSA ABLOY SW300 and
40 kgm
2
for ASSA ABLOY SW150
Inertia = Door weight x (Door width)
2
/ 3
Selectable: 12 V DC, max. 1200 mA or 24 V DC, max. 600 mAElectro-mechanical locking
device:
PUSH arm: 80° - 110°, with reveal 0 - 367 mmDoor opening angle:
PULL arm and Sliding PUSH arm: 80° - 110°, with reveal -20 - 130
mm
Variable between 2.5 - 12 sOpening time (0° - 80°):
Note! If opening time is set to below 3 s, it does not meet the require-
ments of LOW ENERGY, safety sensors must be installed.
Variable between 4 - 12 sClosing time (90° - 10°):
Note! If opening time is set to below 3 s, it does not meet the require-
ments of LOW ENERGY, safety sensors must be installed.
1.5 - 30 sHOLD open time:
-20 °C to +45 °CAmbient temperature:
Max. 95%Relative humidity:
7.6 kgDrive unit weight:
IP20Class of protection:
IP54Degree of protection, con-
trol actuators:
Third party approvals from established certification organizations
valid for safety in use, see Declaration of Conformity.
Approvals:
Complies with: EN 16005, EN 60335-2-103, EN 1634-1
11Issue 2021-02-041007913-en-20.0
4 Technical specifications

Assa Abloy SW300 Specifications

General

Brand	ASSA ABLOY
Model	SW300
Closing Speed	10°/s
Hold-Open Time	Adjustable
Operating Temperature	-20°C to +55°C
