Associated Electrics RC10 B44.2 - Shock and Servo Assembly; Shocks Build - Step 4; Shocks Build - Step 5; Servo Build - Step 1

19
:: Shocks Build - Step 4
:: Shocks Build - Step 5
:: Servo Build - Step 1
7337
Gold
washer
89007
Servo horn
ring
3981
Ballstud, .20
black, short
6272
Dust cover
foam
9180
Servo
horn
1779
FT Servo
mount
6472
Shock
mount nut
91310
12mm shock
spring cup
(5mm offset)
91330
12mm front
spring, Blue
(3.60lb)
91337
12mm rear
spring, white
(2.10lb)
6925
4-40x1/2
shcs
6925
4-40x1/2
shcs
6472
Shock
mount nut
x4
x2
x2
x2
x2
x2
x2
x2
7336
Servo
spacers
6917
4-40x3/8
bhcs
Offset the servo horn by
5-10 degrees
(approximately one notch)
!
(approximately one notch)
!
Servo not
included!
Servo screw
not included!
91304
12mm
threaded
collar
91304
12mm
threaded
collar
o-ring
x4
x4
Front:
8mm
Rear:
5.5mm
Use outside hole
in front arm!
Use inside hole
in rear arm!
!
!
Build x2 front and x2 rear shocks
Racers Tip:
Use your finger to rub
shock oil on the o-ring for
smoother adjustment!
!
