Associated Electrics RC10 B44.2 - Rear Suspension and CVA Assembly; Rear CVA Build - Step 1; Rear Suspension Build - Step 1; Rear Suspension Build - Step 2

15
:: Rear CVA Build - Step 1
:: Rear Suspension Build - Step 1
:: Rear Suspension Build - Step 2
3977
3/16x3/8
bearing
7381
CVA coupler
7996
CVA pin
retainer
9755
CVA axle
rear
9872
FT aluminum
hub tower
(A)
9864
FT aluminum
hub ( 0˚)
9754
CVA bone
rear
7381
CVA cross
pin
6272
Dust cover
foam
7933
Crush tube
3983
Ballstud, .30
black, long
x2x2
x2
x2
x2
6932
4-40x5/16
shcs
7935
.187x.196
bearing
x4
x2
x2
1 drop!
CA glue not
included
Left Side
Left Side
Molded camber link
tower “A” has
standard holes, and
optional “B” tower
has “in-between” hole
options!
!
A
#6588
black grease
Align the gap in
the pin retainer
to be opposite of
the CVA pin.
!
Build x2 (right and left side)
#1597
ca glue
Build x2
7368
3/16
axle shims
7369
1/16
roll pins
9660
2-56 x 7/32
shcs
9890
12mm aluminum
clamping wheel
hex, buggy rear
x4
Build x2 (right and left side)
