Associated Electrics RC10 B44.2 - Steering and Battery Brace Assembly; Steering & Brace Build - Step 1; Steering & Brace Build - Step 2; Steering & Brace Build - Step 3

7
:: Steering and Center Battery Brace Build Step 1
:: Steering and Center Battery Brace Build Step 2
9746
Steering
bearing
set
:: Steering and Center Battery Brace Build Step 3
1mm
9746
Steering
bearing
set
6272
Foam dust
cover
9630
.030
washer
9743
Spring
retainer
9743
Steering
v-spacer
9743
Servo
saver
upper
6277
Ballstud, .30
silver, long
x2
x2
x2
x2
x2
6292
4-40x3/8
fhcs
9900
B44.2
chassis
9743
Steering
retainer
column
9743
Steering
retianer top
6292
4-40x3/8
fhcs
6917
4-40x3/8
bhcs
3874
Black carrier
bushing
9744
5-40
locknut
9744
Servo saver
spring
9743
Servo saver
lower
6272
Dust cover
foam
6276
Ballstud, .20
silver, short
9743
Steering
rack
x2x2
x2
x2
9744
Steering
post
x2
x2
Use the large hole
bearings!
Use the small hole
bearings!
!
!
