INSTRUMENTS/CONTROLS
17 AU104488 C6B
RT160012
The engine controls are accessible through an opening
below the control panel.
THROTTLE CONTROL
Move the throttle control lever (Red) (10) up to increase
the engine speed. Move the control lever down to
decrease the engine speed. It is recommended that you
use maximum engine speed when digging.
RT160057
ENGINE CHOKE CONTROL
Before you start an engine that is cold, pull the choke
control (11) out. Then, after the engine is started and the
engine temperature increases, push the choke control in.
RT160056
10
11
WARNING:
Do not leave the machine
running with the key available while
unattended.
WARNING:
Avoid exposure to dust
containing crystalline silica particles. This
dust can cause serious injury to the lungs
(silicosis).
