WHEELS/TIRES
33 AU104488 C6B
INSTALLING DUAL WHEELS
RT160041
1. Loosen and remove all wheel nuts from the wheel on
the machine.
2. Install a dual wheel bracket on the machine wheel.
3. Install all wheel nuts with the flat side of the nut
against the dual wheel bracket. Tighten the wheel
nuts to 81 to 95 Nm (60 to 70 lb ft).
4. Install the dual wheel against the dual wheel bracket.
Make sure the three spokes on the dual wheel engage
the three cutouts on the wheel on the machine. Also,
make sure the tread pattern on the dual wheel is
facing the same direction as the tread pattern on the
wheels on the machine.
5. Install the dual wheel bolt through the dual wheel and
into the dual wheel bracket and tighten the dual
wheel bolt.
NOTE:
The valve stem on the original wheel must be
toward the machine.
RT160061/RT160062
1. Dual Wheel Bracket
3. Dual Wheel
2. Wheel Nut
4. Dual Wheel Bolt
