conditions.
· The acceptable tolerance to voltage fluctuation is +/-
10%
during operation.
Calor EVO HEAT PUMP
english
MODEL
BLPAM100
BLPAM100R
BLPAM200
BLPAM200R
BLPAM400
BLPAM400R
BLPAM600
BLPAM600R
BLPAM700
BLPAM700R
BLPAT700
BLPAT700R
BLPAM800
BLPAM800R
BLPAT800
BLPAT800R
BLPAT900
BLPAT900R
VOLTAGE /
FREQUENCY (V/Ph/Hz)
230/1/50 230/1/50 230/1/50 230/1/50 230/1/50 380/3/50 230/1/50 380/3/50 380/3/50
SHORT
CIRCUIT
PROTECTION
DEVICE
NOMINAL
CURRENT
2,5 A 3,8 A 8,3 A 12,0 A 16,0 A 6,0 A 21 A 7,8 A 9,6 A
RESIDUAL
CURRENT
LIMIT
20mA 25mA 30mA 45mA 60mA 25mA 100mA 35mA 40mA
FUSE GAUGE
16 A
16 A
20 A
32 A
40 A
20 A
60 A
20 A
20 A
SUPPLY GAUGE
3x1,0
3x1,0
3x2,5
3x2,5
3x4
5x2,5
3x4
5x2,5
5x2,5
D. Electric Diagram of the Heat Pump
See ANNEX 1 for electrical diagram detail.
15
