Appendix A: Component Resistance Tables
Table 1. Hose/Applicator Fuse Size Specification
Voltage Amps
100 4
115 4
200 4
230 4
Table 2. RTD Sensor Resistance
Temperature Ohms
0 °C (32 °F) 100
38 °C (100 °F) 115
66 °C (150 °F) 126
93 °C (200 °F) 136
121°C (250 °F) 147
149 °C (300 °F) 158
177 °C (350 °F) 168
204 °C (400 °F) 178
NOTE: The tank and the hose have one RTD sensor each.
Table 3. Heater Resistance
Tank
Voltage Ohms
230 53
Motor
Voltage Ohms
230 11 - 13
Table 4. E100XT Automatic Applicator Resistance
Voltage Ohms
115 50 - 65
230 216 - 264
56 KB30, KB50 and KB100 Series Hot Melt Units 19600-159 Rev. A 04/09/09 © Copyright Astro Packaging 2009
