STEP 4:
Insert the Pulse Wires (No. E7) into the large hole located on the front of the Post
Tube (No. I) and pull the wires through the top of the Post Tube (No. I). Next, align
the holes of the mounting bracket located on the Handlebar (No. E) with the holes
located on the Post Tube (No. I) and secure the Handlebar (No. E) using 2 Flat
Washers (No. L3), 2 Spring Washers (No. L2) and 2 Allen Bolts (No. L1). Tighten
with Allen Wrench (L4).
