Asus A7N8X Series User Manual

ix
A7N8X specifications summary
CPU
Chipset
Front Side Bus (FSB)
Memory
Expansion slots
IDE
Serial ATA (optional)
Audio (optional)
LAN (optional)
1394 (optional)
Special Features
Back Panel I/O Ports
(continued on the next page)
Socket A for AMD Duron™/Athlon™/Athlon™ XP 2800+ or
higher
333 MHz FSB Support
Northbridge: NVIDIA
®
nForce2 SPP
Southbridge: NVIDIA
®
nForce2 MCP-T (Deluxe Model)/MCP
333/266/200Mhz
3 x 184-pin DDR DIMM Sockets
Max. 3 GB unbuffered PC3200/2700/2100/1600 non-ECC
DDR RAM memory. Dual-Channel DDR400 support.
(Visit ASUS website for latest qualified DDR400 module list.)
5 x PCI
1 x AGP Pro/8X (1.5V only)
2 x UltraDMA 133/100/66/33
Silicon Image Sil 3112A Controller with 2 Ports
(Supports RAID 0/1) (Deluxe model only)
Realtek ALC650 6CH with built-in HP amplifier
Integrated APU (Audio Processor Unit) (Deluxe model only)
SoundStorm™/Dolby® Digital (AC-3) Encoder
(Deluxe model only)
2 Ports
MCP integrated NVIDIA MAC + Realtek 8201BL PHY
MCP integrated 3Com MAC + BroadCom AC101L PHY
(Deluxe model only)
2 Ports MCP-T integrated IEEE 1394a + Realtek PHY
8801B (Deluxe model only)
ASUS Q-Fan Technology
ASUS POST Reporter (Deluxe model only)
ASUS C.O.P. (CPU Overheating Protection)
Power Loss Restart
CPU Throttle
Support S/PDIF in/out (optional)
1 x Parallel
1 x Serial
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x S/PDIF out + 1 x Surround L/R audio jack + 1 x CNTR/
LFE audio jack (Deluxe model only)
1 x Audio I/O
2 x RJ-45 Port (3COM RJ-45 port - Deluxe model only)
4 x USB 2.0

Asus A7N8X Series Specifications

General

Memory Type	DDR SDRAM
Maximum Memory Supported	3 GB
Expansion Slots	1 x AGP 8x, 5 x PCI
Form Factor	ATX
Socket	Socket A
Supported CPUs	AMD Athlon XP/Athlon/Duron
Memory Slots	3 x DIMM
Memory Types	DDR266/333/400
IDE	2 x ATA/133
Audio	6-channel AC'97
