ASUS Xonar Phoebus
5.2 Connecting Digital Speaker Systems (Home Theater)
Xonar Phoebus makes playback through your home theater system possible,
creating an impressive surround sound experience. A single digital cable
connection can carry high-quality digital audio from any of your PC audio sources
to any digital speakers or AV Receivers.
No Item Description
1 Optical adapter
Plug the optical TOSLINK adapter into the S/PDIF-Out
connector.
2 Optical cable
Connectyourdecoder’sS/PDIF-Inporttotheoptical
adapter with the TOSLINK optical cable.
Mic In
Headphone Out
Box Link
Line In
Front
Center / Sub
Rear
SPDIF / Side
2
1
