41
ASUS Xonar Phoebus
No Item Description
1 EQ enable/disable
switch
Click on this check box to enable / disable the Equalizer.
2 EQ band controller
Change the gain setting for each band (30/ 60/ 120/ 250/
500/ 1K/ 2K/ 4K/ 8K/ 16K)
3 Manual mode
Change the gain setting for each band and key in a name in
theinputeld,andthenclicksave to add your new setting.
The new setting will appear in the Manual Mode List. Click
trash to delete settings.
4 Preset mode
Select a preset mode for equalizer that is designed
accordingly. There are 12 preset modes, such as Bass,
Treble, Live, Rock, Jazz and so on.
1
2
6.3.5 Equalizer
Function Introduction
This 10-band EQ function allows you to adjust the EQ band manually and create
customized preset items or click to select a preset EQ mode.
3
4
